SOLDERING LINE

This soldering line is designed for high-

efficiency PCB assembly, integrating
automation, precision soldering, and
quality control. The concept focuses on

flexibility, traceability, and zero-defect
manufacturing, combining loading/

unloading systems, robotic handling,
selective soldering, cooling, and
advanced inspection.

LITE LUD [SNAPVISION] APPLICATIONS

Conveyor with integrated SNAPVISION
optical system AOI. » Electronics manufacturing for automotive,
industrial, and consumer devices.
• Function: Board identification and
orientation check. » Mixed-technology PCBs (through-hole

• Key Features: Vision-based alignment, + SMT).
traceability.
» High-reliability sectors requiring stringent
quality standards (e.g., aerospace, medical).
PEMTRON 3D INSPECTION
» Medium to high-volume production with
Automated Optical Inspection (AOI) system. automated material flow and minimal

• Function: Detects soldering defects and operator intervention.
component misalignment.

• Key Features: 3D measurement, high- TYPICAL PARAMETERS
resolution cameras, SPC data output. » Board Size Range: 50 × 50 – 450 × 350 mm

(adjustable)
» Cycle Time: ~15–30 seconds per PCB
(depending on soldering complexity).
» Soldering Temperature: 250–270 °C (wave
soldering).
» Cooling Time: Configurable, typically 30-60’’.

» Inspection Accuracy: ±10 μm (Pemtron AOI).
» Line Throughput: Up to 800–1200 boards/
hour (depending on configuration).
