HANDLING |
FULLY INTEGRATED
MODULAR CONCEPT SYSTEM
UNIFORM MODULAR LANE CONCEPT
Introducing our uniform Modular UNIQUE CONCEPT
Lane concept, dedicated to backend
processes such as coating, dispensing, » PCBA-pallets dimensions: up to (800x550)
wave soldering (including selective), mm. Max. pallet weight: 20 kg.
depaneling, or exotic component » Component clearance 150 mm top and bottom.
insertion, among others. » Edge clearence: 5 mm.
Experience the perfect blend of » Integrated return conveyor.
» Traceability: Data Matrix, Barcode Reader,
robustness, efficiency, and user-centric RFID (via integration)
design with our LITE LINE system, » Conveyor speed: 300-2.000 mm/min.
featuring an integrated return conveyor » Auto adjust conveyor width from software.
to optimize production flow and reduce » Automated safety shutter.
handling time. » Adjustable on demand electrical power inlet.
Ideal for modern production environments, » Less maintenance. No air pressure required.
it guarantees high performance and » Centralized 125 mm extraction duct.
uptime in every process stage. » High-robustness welded frame chassis.
» Uniform designed electric & PLC cabinet.
FULL INTERCONNECTED TRACEABILITY » HMI with user-friendly UI.
OPTION » Heavy duty chain conveyor.
» SMEMA protocol compliance (Optional
HERMES).
» Process Tracker AI.
» Compatible software: Process Tracker
& .
» Physio ergonomics approved.
» Coherent air flow management.
» Live process parameters log.
