HANDLING | CURING

HIGH EFFICIENCY
ENVIRONMENTALLY

FRIENDLY ALTERNATIVE
TO MERCURY LAMPS.

MORE INFO

ULTRA-FAST CURING IN JUST 10 SECONDS

The UV Irradiation Source has world FACILITY REQUIREMENTS
best efficiency using high power UV
LED panel. It is available either as UV Dimensions (WxDxH) 900 x 1280 x 1648 mm
single frequency or as multi-frequency Approx. weight 400 kg
spectrum from 265 nm toward 405 nm.
Power 7 kW

FEATURES Transmission type Chain | Belt optional
SMEMA height 940-960 mm
» Curing Area: 500x400 mm.
» Curing Side: Top or/and bottom. Voltage 230 VAC
» Power Intensity: 300mW/cm2 at Flow direction L -> R | R -> L optional
50 mm distance from substrate.
» Cooling method: Fans cooling. Fixed rail Front | Back optional
» Electric power consumption: 1800 W. Lamp and product
temperature.
» 2 power irradiation outputs. Cabinet temperature &
» Combined frequencies 265 nm => 405 nm. humidity.
» Easy setup & stable process. Process monitoring Radiation delivered
on demand
» Maintenance free ≡ Highly attractive COO/TCO. power output.
Radiation frequency
OPTIONS recording.

Radiation panel ESD level.
dimension Panel Display: LCD
• Standard: 250 x 400 & operation.
400 x 500 mm. Lamp Controller Power: 0-100%
• On demand: from 50 x adjustable.
50 to 800 x 500 mm. PROCESS TRACKER Temperature monitoring.

MSTECH Europe is part of Incorpora Techno Group 24
